MacDon PW7 Pick-Up Header User Manual
Page 49
SECTION 6 – MAINTENANCE/LUBRICATION
Form 169149
Revision E
43
P00079
6.5 LUBRICATION POINTS
Rake-Up Lubrication Points
A – Drive Shaft
B – Six Small Gear Boxes
(Mirror Model shown)
C – Main Gearbox
(Mirror Model Shown)
D– Belt Tension Idler Arm
E – Height Control Sensor (
If equipped
)
F – Header Drive Chain and Sprocket
SwathMaster Lubrication Points
A – Drive Shaft
B – Height Control Sensor
(If equipped)
C – Header Drive Chain & Sprocket
A
B
C
D
E
B
A
P00667
F
C
