MacDon PW7 Pick-Up Header User Manual
Page 13
SECTION 2
SAFETY
Form 169149
Revision E
7
2.5
SAFETY INFORMATION/SIGN LOCATION
Operators must read and follow all safety information in this manual and on safety signs located
on the machine.
Missing, damaged, or illegible safety signs must be replaced immediately.
All new shields or components must include the latest safety signs.
All safety signs and their locations are shown in the illustrations below. Both three-panel (with
text) and two-panel (graphics only) versions are shown.
Safety signs displaying the “Read Operators Manual” symbol are intending to
direct the operator to the Operators Manual for further information regarding
safety, adjustments, maintenance and/or procedure for specific areas of the unit.
RAKE-UP SPECIFIC SAFETY SIGNS
Rotating Drive Hazard, Pinch Point
Located on Belt Guard
184371 2-PANEL
184386
184397 3-PANEL
184393
