page 80 — wrs5200dfpu hYdrauLIC roLLer sCreed • operatIon manuaL — rev. #0 (08/18/14)
PoWer anD groUnD connections
FRAME
GROUND
T7
T9
FUSE
BOX
5S
NEG.
6S
POS.
ENGINE
GROUND
T11
COUPLER
GROUND
POWER
RELAY
MODULE
STARTER
SOLENOID
ALTERNATOR
12VDC
BATTERY
EMERGENCY
STOP SWITCH
(PU SIDE)
P9
P8
SPLICE
TO ALT
+12VDC
FROM IGN.
F
J1
GRN/BLK
K
J1
+12VDC
INPUT
STUD
+12VDC
OUTPUT
FUSE
15A
T13
T12 T8
60 AMP
FUSE
SWITCHED
20 AMP
FUSE
NON SWITCHED
RED
RED
RED
RED
RED
BLK
BLK
TO +12VDC
SPLICE
BLK
P6
GREEN
A
A
A
