hyDraUlic hoses
table 11. Hydraulic Hoses
Item
number
Destination
From to
1 Stack Valve Port B Drive Tube Motor C, Port C1
2 Stack Valve Port A Drive Tube Motor A, Port A1
3 Stack Valve Port D Drive Tube Motor D, Port D1
4 Stack Valve Port C Drive Tube Motor B, Port B1
5 Stack Valve Port E1 Speed Control Valve Port B1
6 Speed Control Valve Port A1 Solenoid Valve Port A
7 Speed Control Valve Port B2 Solenoid Valve Port B
8 Speed Control Valve Port A2 Hydraulic Tank Interface Plate Port A
9 Stack Valve Port E2 Hydraulic Tank Interface Plate Port B
10 Hydraulic Tank Interface Plate Port B Hydraulic Tank Port H1
11 Hydraulic Tank Interface Plate Port A Control Valve Port D
12 Hydraulic Filter (In) Port A Hydraulic Pump Port E
13 Loop Flushing Valve Port A Strike Tube Interface Plate Port B1
14 Hydraulic Tank Port C Strike Tube Interface Plate Port A
15 Hydraulic Tank Port B Hydraulic Pump Port F
16 Hydraulic Pump Port B Strike Tube Interface Plate Port B2
17 Hydraulic Pump Port D1 Loop Flushing Valve Port B
18 Hydraulic Pump Port A Hydraulic Tank Port F
19 Hydraulic Tank Port J Cooler Port A
20 Cooler Port B Hydraulic Filter (Out) Port A
21 Hydraulic Tank Port F Loop Flushing Valve Port C
22 Hydraulic Tank Port H Control Valve Port B
23 Control Valve Port C Pressure Washer Interface Plate Port B
24 Control Valve Port A Hydraulic Pump Port C
25 Hydraulic Pump Port D2 Strike Tube Motor Port B
26 Strike Tube Interface Plate Port B Strike Tube Motor Port A
27 Strike Tube Interface Plate Port A Strike Tube Motor Port C
28 Drive Tube Motor A, Port A2 Drive Tube Motor B, Port B2
29 Drive Tube Motor C, Port C2 Drive Tube Motor D, Port D2
Refer to Hydraulic Hoses Layout, next page. Reference Parts Manual P/N 36861 for hose part numbers.
