roller screeD assembly
task 5: engine end truss sections (reference
figure 16)
1. Locate the 9 ft. (2.75 m) left-side section of truss F.
This truss section can be identified by the L14 marking
on the top pipe.
2. Next, locate the 5 ft. (1.5 m) left-side section of truss
G. This truss section can be identified by the L marking
on the top pipe. This section of truss is the 5 FT. (1.5 M)
engine end.
3. Reference detail B, and join truss sections F and G
together. Use the 1/2-13X1-1/2 HHCS screws (12)
when joining these two truss sections along with 1/2-
inch flat washers (24) and 1/2-inch nyloc nut (12).
4. Reference detail A and join the 14 ft. (4.26 m) engine
end truss sections F and G to previously assembled
truss sections D and E.
5. Use the 1/2-13X1-3/4 HHCS screws (12) when joining
these truss sections along with 1/2-inch flat washers
(24) and 1/2-inch nyloc nut (12).
NOTICE
When joining truss section F to truss section G, let truss
section F rest on bosses (4) of inner plate for support
and alignment.
Bosses and mounting hardware are factory installed.
task 6: Bearing Installation
If the strike tube bearing has not been installed onto the
middle bracket perform the following:
1. Insert splined shaft into middle mounting bracket as
shown in Figure 16.
2. Place strike tube support bearing onto splined shaft.
3. Secure strike tube support bearing with 7/16-14x2
HHSC screws (2) and 7/16 nyloc nuts (2). Torque
bearing support nuts to 75 FT-LBS ( 102 N.m).
