page 50 — wrs5200dfpu hYdrauLIC roLLer sCreed • operatIon manuaL — rev. #0 (08/18/14)
5. Place the drive tube speed control lever in the straight
up position.
6. Place the strike tube speed and directional control lever
in the neutral (center) position.
startIng (gas mode)
1. Insert ignition key into ignition switch (Figure 42) and
turn key to the on position.
Figure 42. Ignition Switch (ON)
2. Verify that the oil pressure and charge lamps
(Figure 43) are on.
Figure 43. Oil Pressure/Charge Lamps
3. Press the gas/Lp gas rocker switch downward
(Figure 44) on the control box to select the GAS mode,
RED light is OFF.
Figure 44. Fuel Selector Button (Gas Mode)
OFF
ON
START
KEY
ON ON
GAS/LPG
BUTTON
RED LIGHT “OFF”
GAS MODE
4. Press the throttLe rocker switch downward and
verify that the engine speed is set to idle mode,
green light is OFF (Figure 45).
Figure 45. Throttle Switch (Idle)
5. If starting a cold engine or if the temperature is cold,
press the ChoKe button (Figure 46) and hold down
while cranking the engine.
Figure 46. Choke Button
6. Continue turning ignition key to the start position.
7. Listen for engine to start and release key.
8. Let engine idle for 2 to 3 minutes. Listen for any
abnormal sounds.
9. Verify that the oil pressure and charge lamps
(Figure 43) are off.
GREEN LIGHT
“OFF” (IDLE)
CHOKE
BUTTON
PRESS
oPeration
