PERFECT page 14
Setting example “Normal operation“
The oven (UFP500) has to heat up to 180°C at 50% fan speed and with the air valve 20% open. The
monitor function has to operate at 200°C.
180°C
monitor temperature 200°C
°C
h
1. Select operating mode “Normal operation“
After holding down the SET key (approx. 3 sec), the current operating
mode is flashing. Select operating mode I with the push/turn control
while holding down the SET key.
After the SET key has been released the controller is in
operating mode I.
PRINT SETUP
2. Select temperature setpoint
Hold down the SET key and use the push/turn control to select the
required temperature setpoint of 180 °C.
After the SET key has been released the oven briefly flashes the
temperature setpoint. The display then changes to the actual temperature
and the controller starts to control to the selected temperature setpoint
180 °C.
Heating is indicated by the orange heater symbol.
˚C
3. Select fan speed
Turn the push/turn control clockwise until the fan symbol is flashing.
While holding down the SET key, use the push/turn control to set 50%
fan speed.
4. Set air valve for air vent
Turn the push/turn control clockwise until the air valve symbol is flashing.
While holding down the SET key, use the push/turn control to set the
air valve to 20%.
5. Select monitor temperature
Turn the push/turn control clockwise until the overtemperature display
MAX is flashing. Hold down the SET key and use the push/turn control
to set the monitor temperature to 200 °C.
MIN
AUTO
MAX
˚C
