Technical data
Electrical data
EL 1xx CAN/PLC/MPI
4
l
20 LDCDS−EL100 EN 9.0
Screen Typ EL xxx
105m 105 106
Type Touch screen, resistive
Colours 16 grey tones 64 K 64 K
Display diagonal [cm] 14.5 (5.7") 16.3 (6.4")
Visible size [mm] 115 x 86 131 x 98
Resolution [pixels] 320 x 240 640 x 480
Pixel size [mm] 0.33 x 0.33 0.07 x 0.07
Contrast − 400:1 400:1
Brightness [cd/m 2 ] 180 250 250
Angle of view
right
left
top
bottom
[°] −
−
−
− 60
60
40
50 65
65
50
60
Illumination Cathode−ray tube, adjustable
Service life at
25°C [h] 40000 45000 50000
Screen (continued) Typ EL xxx
108 110 110s
Type Touch screen, resistive
Colours 64 K
Display diagonal [cm] 20.3 (8") 26.4 (10.4")
Visible size [mm] 162 x 122 216 x 163
Resolution [pixels] 640 x 480 640 x 480 600 x 800
Pixel size [mm] 0.25 x 0.25 0.33 x 0.33
Contrast 250:1 300:1
Brightness [cd/m 2 ] 400
Angle of view
right
left
top
bottom
[°] 65
65
55
65 60
60
40
50
Illumination Cathode−ray tube, adjustable
Service life at
25°C [h] 50000
