1 About this documentation
1.3 Terminology used
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
CANopen® is a communication protocol based on CAN. The Lenze system bus
(CAN on board) operates with a subset of this communication protocol.
CANopen® is a registered community trademark of the CAN user organisation
CiA® (CAN in Automation e. V.).
EtherCAT® (Ethernet for Controller and Automation Technology) is an Ethernet-
based fieldbus system which fulfils the application profile for industrial real-
time systems.
EtherCAT® is a registered trademark and patented technology, licensed by
Beckhoff Automation GmbH, Germany.
Ethernet specifies the software (protocols) and hardware (cables, connectors,
etc.) for wired data networks. In the form of "Industrial Ethernet", the Ethernet
standard is applied in industrial production plants.
Standard Ethernet is specified in accordance with IEEE 802.3 by the Institute of
Electrical and Electronics Engineers (IEEE), USA.
PROFIBUS® (Process Field Bus) is a widely used fieldbus system for the
automation of machines and production lines.
PROFIBUS® is a registered trademark and patented technology licensed by the
PROFIBUS & PROFINET International (PI) user organisation.
PROFINET® (Process Field Network) is a real-time capable fieldbus system based
on Ethernet.
PROFINET® is a registered trademark and patented technology licensed by the
PROFIBUS & PROFINET International user organisation (PI).
IEC 61131 programming languages
With the Lenze »PLC Designer«, programming of the PLC according to IEC 61131-3 can be carried out. The IEC 61131
standard describes the following programming languages:
SFC
Sequential function chart (SFC) is one of the five programming languages
standardised in DIN EN 61131-3.
• SFC is used for programming a PLC control system in the form of a Petri net.
• Under Siemens STEP® 7, sequential function chart is known as S7 GRAPH.
IL Instruction lists (IL) are mainly used for logic operations of control inputs and
outputs. Typically, a (digital) input is loaded into the working register
(accumulator) (load digital input 0, "LD %IX0.0"), linked with other inputs,
constants, or memory values (exclusive-OR memory bit 3, "XOR %MX0.3"), and is
written to an output (store digital output 1, "ST %QX0.1").
CFC CFC (Continuous Function Chart) is a language similar to FBD.
• FBD editors are network-oriented and arrange the function blocks
automatically. CFC enables the free arrangement of all function blocks, which
makes it possible to program feedback loops without interim variables.
• CFC is convenient for representing application overviews.
FBD Function block diagram (FBD) is a graphical programming language within
STEP® 7 and there corresponds to the function block language as PLC
programming language in accordance with EN 61131-3 [1] to a large extent.
The function block diagram (FBD) has been defined as a project planning tool for
sequence control systems in the former DIN 40719. [1]
Grafcet in accordance with EN 60848 has replaced FBD. Both languages are
similar to the sequential function chart (SFC) as PLC programming language in
accordance with EN 61131-3. With Siemens STEP® 7 this language is called S7-
GRAPH.
LD Ladder diagram is a graphical programming language standardised in the IEC
standard DIN EN 61131-3, that represents a graphical diagram based on circuit
diagrams.
• LD is primarily used for programmable logic controllers.
• If the elements are connected in series this is an AND operation. If the
elements are connected in parallel this is an OR operation. A line across the
element indicates a negation of the element.
• Inputs are represented as two vertical parallel lines, outputs are represented
as two opposite curved lines.
Term Meaning
