Lenze · Controller-based Automation - Visualisation · System Manual · DMS 1.5 EN · 04/2014 · TD17

7

1

About this documentation

1.2

Conventions used

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

1.2

Conventions used

This documentation uses the following conventions to highlight different types of information:

Type of information

Writing

Examples/notes

Spelling of numbers
Decimal

Normal spelling

Example: 1234

Decimal separator

Point

The decimal point is always used.

For example: 1234.56

Hexadecimal

0x[0 ... 9, A ... F]

Example: 0x60F4

Binary

• Nibble

0b[0, 1]

Example: ’0b0110’

Example: ’0b0110.0100’

Text
Version information

Text colour blue

All information that only applies to or from a certain

software version of the inverter is marked correspondingly in

this documentation.

Example:

This function extension is available from software

version V3.0!

Program name

» «

»PLC Designer«...

Window area

Italics

The Message window... / The Options dialog box...

Variable identifier

By setting bEnable to TRUE...

Control element

Bold

The OK button... / The Copy command... / The Properties

tab... / The Name input field...

Sequence of menu

commands

If several commands must be used in sequence to carry out a

function, the individual commands are separated by an

arrow. Select File

Open to...

Shortcut

Use to open the online help.
If a key combination is required for a command, a "+" is

placed between the key identifiers: With +...

Hyperlink

underlined

Optically highlighted reference to another topic. It is

activated with a mouse-click in this online documentation.

Icons
Page reference

( 11)

Optically highlighted reference to another page. In this

online documentation activated via mouse-click.

Step-by-step instructions

Step-by-step instructions are marked by a pictograph.
