Instrument components and specifications – Leica Biosystems ST5020 User Manual
Page 15

15
Leica ST5020
Capacity data
Specimen slide throughput:
depending on the program-structure
Loading capacity:
max.12 slide racks (with 12 different Programs)
Slide rack capacity:
30 specimen slides
Total number of stations:
40 (36 + 4 Oven)
Total number of reagent stations:
max. 34
Reagent container volume:
450 ml
Number of wash stations:
max. 5 and 1 DI-water (optional)
Oven (optional):
2 or 4
Oven chamber temperature:
40 °C to 70 °C or 104 °F to 158 °F
Incubation time setting:
0 sec. up to 23 hours, 59 min., 59 sec.
Load/unload stations:
max. each 4, min. each 1
Permanent memory capacity:
max. 50 Programs, up to 40 program steps each
Integration:
connection to Leica CV5030 Coverslipper (optional)
Dimensions and weight
Basic instrument (W x D x H), in mm:
1060 x 750 x 540
Dry weight, unpacked:
ca. 90 kg
Weight, packed:
ca. 110 kg
3.
Instrument components and specifications
