Specifications
SPECIFICATIONS
Planter Size 4 Row 30" 6 Row 30" 8 Row 30"
Single Frame Length 11'4" (3.5M) 11'4" (3.5M) 11'4" (3.5M)
Double Frame Length 13'8" (4.2M) 13'8" (4.2M) 13'8" (4.2M)
Width 12'8" (3.9M) 17'8" (5.4M) 21'10" (6.7M)
Single Frame Weight* 2538 lb
(1151.22 kg)
3864 lb
(1752.68 kg)
4874 lb
(2210.81 kg)
Double Frame Weight* 2948 lb
(1337.19 kg)
4398 lb
(1994.90 kg)
5548 lb
(2516.53 kg)
Seed Capacity 1.90 bu. (Mechanical / Hopper)
Transport/Field Tire 7.50" x 20" 8 ply rib implement tires with center groove ............Inflate to 40 psi (275.7 kPa)
Contact Drive Tire 4.10" x 6" ...................................................................................Inflate to 50 psi (344.7 kPa)
Field Lift Master / slave rephasing cylinders
Row Markers Hydraulic alternating sequence valve (dual valve optional), single fold, depth bands.
* Base machine weights include planter frame including row markers, drive components, tires and wheels, hydraulic
cylinders, transport safety chain and Kinze pull row units (closing wheel arms less wheels) with seed hopper and lid
and dual quick adjustable down force springs.
TRACTOR HYDRAULIC REqUIREMENTS
Configuration Requirements Description
Base machine with mechanical
meters and row markers
1 SCV
10 gpm
(38 L/min)
#1 SCV: Planter lift and row marker auto sequencing
Base machine with mechanical
meters and row marker dual valve
conversion
2 SCV
10 gpm
(38 L/min)
#1 SCV: Planter lift
#2 SCV: Row markers with optional dual valve
GENERAL INFORMATION
This manual covers all production years of the Model 3000 planter. Contact your Kinze dealer for additional options which
may be available for your specific model year planter.
Information in this manual was current at time of printing. However, due to Kinze’s ongoing product improvement,
production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing, Inc. reserves the
right to change specifications or design without notice and without incurring obligation to install the same on machines
previously manufactured.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing in the direction the
machine will travel when in use, unless otherwise stated.
TOOLS REqUIRED
Hardware Size / Tool Required
1/4 " = 7/16" 7/16 " = 5/8"
(nut for 7/16" hardware uses 11/16" tool)
3/4 " = 11/8" 11/4" = 17/8"
5/16 " = 1/2" 1/2 " = 3/4" 7/8 " = 15/16" 11/2" = 21/4"
3/8 " = 9/16" 5/8 " = 15/16" 1" = 11/2"
