M0188-01 Model 3000
6-8 Rev. 6/11
TM
KPM II Monitor Operation
MONITOR KEY FUNCTIONS
Push keys allow the user to select or change the
operating mode, the active displays or the current
configuration. Depending on the operating mode or
the current display selected, some keys are valid
while some are not. Each key press, if valid, is
acknowledged by a short beep and an action is taken.
If the key press has no action associated, the key
press is considered invalid, and the user will not get
any feedback.
SELECT
• Selects the application mode (rear/front, left/right or
four sections up to a maximum of 72 rows) at the
beginning of installation in the setup mode.
• Selects the active section(s) (rear, rear/front, left,
right or left/right) in the operation mode.
• Has no affect on a system configured to monitor
only one section.
• While programming the monitor, the key will select
the digit to change.
SPEED
• Immediately displays current ground speed.
SCAN
• If the current average population or average spacing
is displayed, this key sequentially displays the seed
population/spacing on each row.
• If display shows functions other than average seed
population or spacing, pressing SCAN sequentially
displays speed, average seed population and
average seed spacing.
• Pressing a second time freezes display on the
current row.
• Pressing a third time restarts sequential display.
SEED POPULATION/SEED SPACING
• Immediately
displays the average seed
POPULATION and the average seed SPACING of
all active rows.
• Each press alternates between seed spacing and
seed population.
AREA FIELD/AREA TOTAL
• Immediately displays the field or total area planted
since the field/total area was last cleared.
• Each press alternates between field area and total
area.
OK
• Ends and saves the new setup during installation.
• Acknowledges and silences alarms in the operation
mode.
UP ARROw AND DOwN ARROw
• Scrolls sequentially through the display options on
the lower LCD display.
• Freezes on the current row in the scan mode.
• Scrolls sequentially through the rows when the
population scan is frozen.
• Used to enter programmable values in the
programming mode.
• The UP and DOWN Arrow keys can be pressed at
the same time to start the CLEAR function.
SETUP ENTER/SETUP ExIT
• Enters and exits the programming mode.
ON/OFF
• Powers unit on and off.
