TM
Model 3000 M0188-01
Rev. 2/14 2-3
Machine Operation
CYLINDER INFORMATION
Row Marker Cylinder
(4 Row 30"/36"/38"
and 6 Row 30")
Row Marker Cylinder
(6 Row 36"/38" and
8 Row 30")
Lift Assist Cylinder
(6 Row 30"/36"/38"
and 8 Row 30")
Slave Lift Cylinder Master Lift Cylinder
Intended Use
Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Piston Ductile Iron Ductile Iron Ductile Iron Ductile Iron Ductile Iron
Gland Ductile Iron Ductile Iron Ductile Iron Ductile Iron Ductile Iron
Tube ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing
Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod
End Mounts U-Brackets Sleeve End Mount
Sleeve Tunnion
Mount
Sleeve Tunnion
Mount
Sleeve Tunnion
Mount
Tube Seal
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Rod Seal
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Rod wiper
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Piston Seal T-Seal HNBR T-seal HNBR T-Seal HNBR T-Seal HNBR T-Seal HNBR
Specifications
Product
Category
Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder
Maximum
Stroke
8" (20.32 cm) 20.062" (50.96 cm) 8" (20.32 cm) 8" (20.32 cm) 8" (20.32 cm)
working
Pressure
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
Bore Size 2" (5.08 cm) 2" (5.08 cm) 2.5" (6.35 cm) 3.25" (8.255 cm) 3.5" (8.89 cm)
Shaft
Diameter
1" (2.54 cm) 1" (2.54 cm) 1.25" (3.175 cm) 1.25" (3.175 cm) 1.25" (3.175 cm)
Cylinder
Configuration
Simple Simple Simple Simple Simple
Cylinder
Action
Double Double Double Double Double
Material Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron
Mounting
Method
U-Bracket Sleeve
Sleeve Trunnion
Mount
Sleeve Trunnion
Mount
Sleeve Trunnion
Mount
Mount
Location
End Cap End Cap End Cap End Cap End Cap
Cylinder
Style
Welded Welded Welded Welded Welded
