KPM II Monitor Operation
NOTE: If a discrepancy occurs and digits must be changed, follow STEPS 1 and 2 to enter the programming mode
and proceed as follows:
•Press the OK key and the flashing arrow becomes solid. The least significant digit of the displayed value will be
blinking.
•This value can be changed by pressing UP or DOWN arrow keys.
•Once digit is correct, press the SELECT key and the blinking digit moves to the next significant digit, where the
process can be repeated.
Pulses per mile or kilometer are limited to a range from 500 PPM (310 PPKM) to 500,000 PPM (310,686 PPKM).
KEY Action
Flashing Digit Display Value
Press The UP Key Right Most Digit 203 1, 2032, 2033
Press The SELECT Key Second Digit From Right 20 33
Press The DOWN Key
Second Digit From Right 20 23, 2013, 2003, 2093, 2083
Press The SELECT Key Twice
Left Most Digit 2083
Press The DOWN Key
Left Most Digit 1083, 0500 (Min. Value), 9500, 8500
•To reset counter, press the UP and DOWN
arrow keys at the same time and hold them
down for a short period of time to clear the
data. The CLEAR? icon will be displayed
and the monitor will beep several times.
When the data is actually cleared, the
monitor will emit a long beep, and the total
area is reset to zeros. After the long beep,
the previous recorded total area is not
retrievable. Once cleared, the user may not
choose to exit programming mode without
saving as described in STEP 4.
STEP 4 To exit and save, press and hold the OK key.
The monitor emits several short beeps and
SAVE? icon is turned on. After a short time
a long beep is heard, and the lower LCD
will display the word “DONE”. Release the
OK key. If the OK key is released BEFORE
the word “DONE” is displayed, the changes
WILL NOT BE SAVED. The word “DONE”
MUST be displayed in order for the save to
have occurred.
NOTE: Programming mode may be exited at any
tim by pressing the SETUP key. Pressing this
key returns the monitor to its normal operation.
All items changed and saved come into effect
immediately. Any items changed, but not saved
revert to original programmed value.
PROGRAMMING - CLEARING TOTAL AREA
NOTE: Clearing the total area counter will also
clear the field area counter.
STEP 1 To enter the programming mode, press
and hold the SETUP key. The monitor will
emit several short beeps followed by a long
beep. On the lower LCD, the SETUP icon
turns on and the arrow head icon will flash,
indicating that the user can select an item
to program.
NOTE: Monitor must be in a programmable
function (row spacing, units, speed, volume or
area) to enter setup. The monitor will not enter
setup in seed population or seed spacing.
STEP 2 Press tUP or DOWN arrow keys to move
flashing arrow to TOTAL AREA. As the arrow
icon moves, the lower LCD will display the
current setting of the item selected.
STEP 3 Press the OK key and flashing arrow
becomes solid and audible alarm sounds.
•The lower LCD will display the total area
and the ACRE (or Ha) icon turns on.
•With the flashing arrow on TOTAL AREA,
press the OK key.
