TM
Model 3000 M0188-01
Rev. 6/11 7-3
Lubrication and Maintenance
Pull Row Unit And/Or Push Row Unit Parallel
Linkages (8 Per Row) Row Unit Mounted Bed Leveler Parallel Linkages
(6 Per Row)
Row Unit “V” Closing wheel, Covering Discs/
Single Press wheel And/Or Drag Closing wheel
Eccentric Bushings (2 Per Row)
Row Unit Mounted Disc Furrower Parallel
Linkages (6 Per Row)
BUSHINGS
Lubricate bushings at frequency indicated.
Check each bolt for proper torque. If bolt is loose, removed it and inspect bushing for cracks and wear. Replace
bushing if necessary. Use
only hardened flat washers. Replace damaged flat washers with proper part. Torque
hardware to 130 ft-lb (176.2 N-m).
