99
5 Setup program
Enable extra
codes This function is intended for later extensions within the paperless recorder
(e. g. enabling the extra code for “Integrators, counters, math and logic
module”).
After starting up the function, the function must be used
to read out a code number from the device, and then passed on to the
manufacturer. The manufacturer will then generate a “release number”. The
function is used to transmit this release number to the
device, which will then enable the new device functions.
Calibration/
Test This carries out a calibration and various test functions. Calibration can only
be carried out with a special license number, and is reserved for the
manufacturer’s service personnel.
After activating Extras ➔ Calibration / Test and confirming the security
instruction, a device must be selected, if one is not already connected. The
dialog window will then appear, the hardware and software are automatically
read out, and information about the result will be displayed.
H
Some test functions cannot be terminated as long as there is a
connection to the instrument. If necessary, use the dialog window
to close down the connection.
Test functions
Break
connection
