3 Operation and visualization
48
Standard texts The recorder offers standard texts as listed in the following table:
Supplementary
text The recorder automatically supplements the texts by “ON” or “OFF” in order to
distinguish between the appearance and disappearance of the signal.
Example:
Standard text Comment
Channel x low alarm ON
Channel x low alarm OFF
Channel x high alarm ON
Channel x high alarm OFF
Counter/int. alarm x ON
Counter/int. alarm x OFF
Binary input y
ON
Binary input y OFF
Logic channel y ON
Logic channel y OFF
x = channel number
y = input number
Counter x: y x = counter channel number
y = counter value (9 digits)
Power ON
Power OFF
Data lost
Summer time start
Summer time end
New configuration
Counter/int. x reset from y to z x = counter/int. channel number
y = old counter/int.value (9 digits)
z = new counter/int. value (9 digits)
“Text 1 — 18” 18 freely definable texts
with 20 characters each
Standard text Supplementary
text Entry in event list
Binary input 2 ON Binary input 2 ON
Binary input 2 OFF Binary input 2 OFF
