93
5 Setup program
TCP/IP PORT The following parameters must be selected:
Analog
modem /
ISDN The following parameters must be selected:
Serial
interface The following parameters must be selected:
IP address /
HOST name xxx.xxx.xxx.xxx
(Example: 192.168.0.10) Enter the IP address of
your device. If you enter
the name, the IP
address can be
determined by clicking
on the button “Convert
HOST name to IP
address”.
Port number,
port name 502 The port used for
communication.
Communications
protocol Modbus TCP/IP,
Modbus protocol Set the
Modbus TCP/IP here.
Communications
password 0 The communications
password must match
the one that has been
set in the device.
Telephone number Enter the telephone
number for connecting
to the required device.
Connect via Select the modem that
is to be used to make
the connection.
Communications
protocol Modbus TCP/IP,
Modbus protocol Set the
Modbus protocol
here.
Device address 1 — 255 (255 can only
be set if just one device
is connected) Device address for the
Modbus protocol.
Communications
password 0 The communications
password must match
the one that has been
set in the device.
Connected to COM1, COM2 The PC interface to
which the paperless
recorder is connected.
