4 Configuration parameters
4.2.10Configuration - Interfaces
Parameter Value/Selection Description
Serial interface
Interface type Configuration
➔ Interfaces
➔ RS232/RS485
➔ Interface type
RS232,
RS485 Parameters for the serial
interface (extra code)
Protocol Configuration
➔ Interfaces
➔ RS232/RS485
➔ Protocol
MODbus,
Jbus
Baud rate Configuration
➔ Interfaces
➔ RS232/RS485
➔ Baud rate
9600 bps,
19200 bps,
38400 bps
Data format Configuration
➔ Interfaces
➔ RS232/RS485
➔ Data format
8-1-none,
8-1-odd,
8-1-even,
8-2-none
Device address Configuration
➔ Interfaces
➔ RS232/RS485
➔ Device address
1 — 254
Min. response time Configuration
➔ Interfaces
➔ RS232/RS485
➔ Min. response time
0 — 500ms
Ethernet interface
IP address Configuration
➔ Interfaces
➔ Ethernet
➔ IP address
000.000.000.000 …
192.168.000.010 …
255.255.255.255 The IP address for the
recorder is set here.
Subnet mask Configuration
➔ Interfaces
➔ Ethernet
➔ Subnet mask
000.000.000.000 …
255.255.000.000 …
255.255.255.255 The subnet mask is set
here.
Devices are combined into
subnets through the sub-
net mask. All devices
whose IP address, when
AND-linked, is identical to
the subnet mask, belong to
one subnet and can thus
communicate with each
other.
Gateway Configuration
➔ Interfaces
➔ Ethernet
➔ Gateway
000.000.000.000 …
255.255.255.255 The address for the
standard gateway is set
here. Devices that do not
belong to a subnet can
communicate through the
standard gateway.
