8 Identifying the instrument version
8.1 Type designation
Entry-level paperless recorder with CompactFlash card as storage medium
and life-cycle data management
(1) Basic version
706510/14 Paperless recorder with 3 analog inputs
706510/24
Paperless recorder with 3 analog inputs
incl. setup and PC evaluation program (PCA3000)
706510/15 Paperless recorder with 6 analog inputs
706510/25
Paperless recorder with 6 analog inputs
incl. setup and PC evaluation program (PCA3000)
(2) Supply voltage
x x x x 22 20 — 53V AC/DC, 48 — 63Hz
x x x x 23 110 — 240 V AC +10/-15%, 48 — 63Hz
(3) Extra codes
x x x x 008 Ethernet interface
x x x x 020 Lithium battery for memory buffering (ex-factory)
x x x x 021 Storage capacitor (instead of extra code 020)
x x x x 260 Integrators and counters, as well as math and
logic module (the math and logic module can only be
configured through the setup program).
x x x x 261 4 binary inputs, 3 relay outputs,
serial interface RS232/RS485 (Modbus, Jbus)
x x x x 265 Door with lock (IP54)
x x x x 266 IP65 seal, 4 wide mounting brackets
x x x x 350 Universal carrying case TG-35
1
(1) (2) (3)
Order code - / , ...
2
Order example 706510/14 - 23 / 020
1
This extra code is available in combination with supply voltage
110 — 240 V AC, not with low supply voltage.
UL approval is not available.
The protection type in the carrying case corresponds to IP20, outside IP20D.
2
List extra codes in sequence, separated by commas.
