4 Configuration parameters
68
Unit Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Unit
5 characters Enter the unit which is
displayed on the recorder
screen, together with the
entered text and the
current count.
Decimal place Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Decimal place
Automatic,
X.XXXX, XX.XXX,
XXX.XX, XXXX.X,
XXXXX. Specify the decimal place
for displaying the count on
the recorder screen.
Counter text Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Counter text
Standard text,
Text 1 — 18,
No text The text selected here will
appear in the status line
and the event list if the
counter is incremented
(decremented).
Alarm Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Alarm
➔ Alarm
Off,
Activated
Limit value Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Alarm
➔ Limit
-99999 to 100 to +99999 An alarm is triggered when
the limit is infringed. Using
the parameter Weighting, it
is possible to differentiate
between going above or
below the limit (positive
weighting factor = alarm on
going above the limit)
Alarm text Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Alarm
➔ Alarm text
Standard text,
Text 1 — 18,
No text On going above/below the
limit, the text selected here
will appear in the status
line and the event list.
Synchroniz.
time Configuration
➔ Counter/integrator
➔ Synchronizat. time
any time
(00:00:00) Please enter the time at
which the daily, weekly,
monthly or yearly counter/
integrator value is to be
saved.
Period Configuration
➔ Counter/integrator
➔ Period
1min, 2min, 3min, 4min,
5min, 10min, 15min,
30min, 1h, 2h, 3h, 4h, 6h,
8h, 12h Only programmable, if the
parameter Type is set to
“periodic” on at least one
counter/integrator.
The counter/integrator
values are saved at the
selected interval.
Parameter Value/Selection Description
