67
4 Configuration parameters
Input signal Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Input signal
Analog inp. 1 — 3(6),
Math channel 1 — 6 The parameter can only be
programmed if “Integrator”
has been selected under
Function.
Please select which input
is to be integrated.
Weighting Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Weighting
-99999 to +1 to +99999 Select the weighting factor
here.
If, for instance, 0.001 is
entered, then a conversion
can be achieved from liter/
sec to m³. If a negative
weighting factor is entered
(e.g. -1), the counter will
count down.
Time base Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Time base
Second,
Minute,
Hour,
Day The parameter can only be
programmed if “Integrator”
or “Operating time” has
been selected under
Function.
Integrator:
Select the time base for
integrating the selected
channel (second, for
example, if your sensor
generates a signal in liters/
second).
Operating time:
Select the unit used for
counting the time.
Threshold value Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Threshold
value
0 — 99999 The parameter can only be
programmed if “Integrator”
has been selected under
Function.
Enter the threshold value
that has to be exceeded
for integration to proceed.
Channel name
(line 1) Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Channel name
12 characters
Counter/int.
The text that has been
entered appears together
with line 2 and the current
count on the recorder
screen (visualization and
event list).
v Chapter 3.2.7
“Counters / integrators /
operating time”
Channel name
(line 2) Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Channel name
12 characters
Channel 1 — 6
The text that has been
entered appears together
with line 1 and the current
count on the recorder
screen (visualization and
event list).
Parameter Value/Selection Description
