4 Configuration parameters
70
4.2.6 Configuration - Recording
Parameter Value/Selection Description
Analog channels
Input signal Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Input signal
Analog input 1 — 6,
Math channel 1 — 6 Select which channel is to
be recorded (stored).
Channel name Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Channel name
16 characters
Analog channel 1 — 6 The channel name is
shown in the channel line
(header) for bar graph and
scaling.
Unit Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Unit
5 characters
%
Decimal place Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Decimal place
Automatic,
X.XXXX, XX.XXX,
XXX.XX, XXXX.X,
XXXXX. Automatic: representation
with maximum resolution
Line width Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Line width
Thin,
Thick Line width of the
measurement curve within
the graphical display
Alarm Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Alarm
➔ Alarm
Off,
Activated
Low limit Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Alarm
➔ Low limit
-99999 to 0 to +99999
High limit Configuration
➔ Recording
➔ Analog channels
➔ Analog channel 1 — 6
➔ Alarm
➔ High limit
-99999 to 0 to +99999
