2 Device description
28
2.11 Webserver
If the paperless recorder is equipped with the extra code 008 “Ethernet inter-
face”, and the device-internal Ethernet software (“Ethernet version“) has the
number 183.02.03 or higher, then the paperless recorder has an inbuilt web-
server. The webserver can be started by entering the IP address in an Internet
browser on the PC (e.g. http://10.10.90.45).
The variables that are shown are acquired and displayed automatically by the
webserver. The latest data are read out of the instrument every 5 seconds. Any
limit infringements show a red background. A maximum of 6 channels (analog
or math channels), up to 6 counters or integrators, and a maximum of 6 event
traces.
Device name
Analo
g
channels
Counters / integrators
Event trac
es
