Figure 1-17 – INFICON Front Load Single Sensor User Manual
Page 37
1 - 27
PN
07
4-
15
6N
Front Load Single and Dual Sensors Operating Manual
Figure 1-17 2.54 cm (1 in.) bolt feedthrough with three tubes, one coax (PN 750-030-G1)
19.0 (0.75)
Coax Connector
Viton O-ring #2-122
#1-14-UNS Thread
127.0 (5.00)
BNC Connector
View A-A
127.0 (5.00)
9.7 (0.38)
50.8 (2.00)
323.8
(12.75)
Washer
19.0 (0.75)
12.70 (0.500)
6.35 (0.250)
7.11
(0.280)
3.18
(0.125)
A
A
4.78
(0.188)
Dimensions are shown
millimeter (inch)
Mating air fitting (10-32) for
PN 750-420-G1 Solenoid Valve
