7 Maintenance
7.1 Maintenance schedule
Required tools
• 2 screw drivers, size 2
• 1 ring spanner wrench, 19 mm
• 8 mm hexagonal screw driver (delivered with Protec P3000).
Key for Maintenance Schedule:
• I Repair level I Customer
• II Repair level II Customer with technical training from INFICON
• III Repair level III INFICON service engineer
1) Depends on the environment
Warning
For all maintenance on the Protec P3000, the main power must be disconnected
first.
Required maintenance
Sub
Assembly
Material
Description
Part no.
Operation hours
Repair
level
2000 5000 10.000
Check sinter filter and
replace if necessary
Sniffer tip
Sinter Filter for
Sniffertip SL3xx,
SL3000-x (5 pcs.)
200 03 500 X I
Replace if W35 „Flow too
low“
Sniffer tip
Felt for Capillary Filter SL3xx,
SL3000-x (50pcs.)
200 001 116 1) I
Check internal filter and
replace if necessary
Main Unit internal Filter (10 pcs.) 200 001 680 X II
Maintenance of
diaphragm pump
Diaphragm
Pump
MVP015
Wearing parts kit for
Diaphragm pump
200 03 504 X III
Clean or replace the air
filter at the bottom of the
chassis
Main Unit
Air Filter Protec P3000
(104x154 mm; 5 pcs.)
200 001 552 X I
Replace gas reservoir
after 1 year
PRO-Check
Replacement gas reservoir
for PRO-Check
521-010 1) I
Replace filter pad Sniffer tip SL3000-XL 200 002 251 I
