C
Emergency Modules
37
Step 5:
Terminate the neutral as described below dependant on your rack type.
Single Pole Racks
For racks which have neutral jumpers fitted, the neutral of the load fed by the emergency
module should be connected to the neutral terminal of an adjacent module.
Neutral Disconnect Racks
In racks without neutral jumpers (Neutral Disconnect racks) the neutral of the load should
not be connected to another load’s neutral terminal. This can cause unwanted tripping of
RCD modules. Instead, an auxiliary neutral terminal must be fitted to the neutral plate and
the loads should be connected to the terminal. If your rack was ordered with Emergency
Modules the auxiliary neutral terminal should be factory fitted. If you require an auxiliary
neutral terminal, please contact ETC as shown using the details in
C A U T I O N :
It is important to correctly identify the Constant Live, Dimmed Live and Neutral
wires, as incorrect termination can cause damage to the fixture and/or dimmer
rack.
