Land Load Wires 17
Installing Three-Slot Dimmer Lug Strips
Step 1: Use a Phillips screwdriver to remove the two
screws securing the lug strip to the left side
of the rack.
Step 2: Remove the lug strip and replace it with one
containing a three-slot Neutral jumper.
Step 3: Secure the strip to the rack with the screws
you removed in Step 1.
Secure the jumper to the main Neutral bus PEM inserts
using the two screws provided with the jumper.
Figure 17: Removing or installing a
Neutral lug strip
