ETC Matrix MkII Rack User Manual
Page 7
Introduction
3
Rack version
Rear access
Swing frame
Rack height
1.6m
2.0m
2.0m
Channels (max)
72
108
72
54
108
162
108
81
108
162
108
81
7541A--
Ref. no: 7542A--
1714
1715
1716
1723
1717
1718
1719
1724
1720
1721
1722
1725
7541A1200
iSW Relay 4x16A,
RCBO/ch current
sensing
7541A1201
iSW Relay 6x16A,
MCB/ch, current
sensing
7541A1202
iSW Relay 6x16A,
RCD, MCB/ch,
current sensing
7541A1312
Dual processor
7541A1401
iCON Constant
power 6x16A,
MCB/ch
7541A1402
iCON Constant
power 6x16A,
RCD, MCB/ch
7541A1403
iCON Constant
power 4x16A,
RCBO/ch
7541A1405
iCON Constant
power 1x63A,
RCD, MCB
7541A1406
iCON Constant
power 3x32A,
RCBO/ch
7542A1501
Airflow module
