Matrix MkII Racks – standard range
Rear Access Rack max capacity (160cm high)
Rear Access Rack max capacity (200cm high)
7541A1714: 72 x 16A
7541A1715: 108 x 16A
7541A1715: 54 x 32A
7541A1716: 72 x 16A or,
60 x16A and12 x 32A
7541A1717: 108 x 16A
7541A1718: 162 x 16A
7541A1724: 81 x 32A
7541A1719: 108 x 16A or,
84 x16A and 24 x 32A
Swing Frame Rack max capacity (200cm high, front access)
7542A1720: 108 x 16A
7542A1721: 162 x 16A
7542A1725: 81 x 32A
7542A1722: 108 x 16A or 84 x16A and 24 x 32A
