ERICO CADWELD for Rebar Splicing System User Manual
Page 3
1
www.erico.com
Table Of Contents
General Safety Information...............….............................................................................IFC
Rebar Cleaning Procedure (Preparation) …………............................................................... 2
Instructions for Vertical Splicing (Bar-to-Bar) .................................................................... 3-4
Instructions for Horizontal Splicing …………....................................................................5-6
Filler Material Remixing and Placement Procedures............................................................. 7
Venting CADWELD
®
Horizontal Splices ……….................................................................... 8
Inspection …….................................................................................................................. 9
Eccentricity and Cocking of Rebars ……………................................................................. 9
Rejection of a Splice and Its Causes................…................................................................10
Void Limits.........................................................................................................................11
Additional Instructions for B-Series.................................................................................... 12
Welding of Splice Sleeves to Structural Steel......................................................................12
Care of Finished Assemblies...............................................................................................12
Addenda ...........…........................................................................................................... 13
External Bar Reference Marks ...........….............................................................................13
Bar End Gap ……..............................................................................................................13
B-Series Sleeve Repair........................................................................................................ 13
Tap Hole Relocation...........................................................................................................14
Use of Sleeves Out of Their Normal Position..................................................................... 15
Repair of Bar-to-Bar Production Splice Samples or Rejected Splices....................................15
Traceability....................................................................................................................... 15
