14 figure 13—detector terminal block – Det-Tronics R7495D UV/IR Flame Detection System User Manual
Page 14
14
Figure 13—Detector Terminal Block
D0947
+
24 VDC (A)
OUTPUT SIGNAL (B)
CIRCUIT GND (C)
oi
SIGNAL (D)
EARTH GND
Figure 12—C7052J Detector Part Identification
F0946
JUNCTION BOX
JUNCTION BOX COVER
MOUNTING PIN
IR TEST LAMPS (2)
O-RING
IR SENSOR HOUSING
IR
oi
RING
INDEX PIN
UV SENSOR MODULE
O-RING
UV TEST LAMP OPENING
UV SENSOR HOUSING
UV
oi
RING
IR SENSOR MODULE
UV TERMINAL BLOCK
