Control Page
The Control Page contains various parameters which control miscellaneous functions.
To access the Control Page, enter the Setup Mode. Press the Page key until Control is
displayed. Press the Menu key. Each parameter can be changed by pressing the Menu
key until the desired parameter is displayed, and then pressing the
keys to change
the value.
Menu Item Display Description Range
Cycle Time Control Cycle
Time Sec Set cycle time in seconds for
control output 1 to 60 seconds
High limit
setpoint Control Hi-Lim
SP*** Maximum value for all high limit
setpoints MinHiLimSP - MaxHiLimSP*
High limit
band Control Hi-Lim
Band If=0, high limit setpoint= Control
Hi-Lim SP If>0, high limit
setpoint= Control SP* + Band Off, 3°C to 11°C (5°F to 20°F)
Power fail
recovery Control PwrFRec Controls response to loss of
power
Stop, Restart, Hold, Resume
Recovery
time limit Control PFRTime Control aborts to Stopped mode if
power is lost for time period
longer then set value
00m00s to 99m59s
Powerup
start enable ControlPwrUpStrt Allows mode to automatically
start when power is first applied
Disable, Enable
Powerup
Start Mode Control StrtMode Operating mode for powerup start Off, Manual, Timer, Pro-1 to Pro-8
Hysteresis Control
Hysteresis Hysteresis for all alarms and
temperature events 1°C to 56°C (1°F to 100°F)
Process out
low Control
RetOutLo Process value for retransmit
output = 1VDC -73°C to 760°C (-100°F to 1400°F)
Process out
high Control RetOutHi Process value for retransmit
output = 5VDC
-73°C to 760°C (-100°F to 1400°F)
Time scale Control
TimeScale Time scale setting for program
and timer mode** hh:mm or mm:ss
Key press
beep Control KeyBeep Internal beeper sounds when key
is pressed On or Off
End of cycle
beep Control
EOCBeep Internal beeper sounds at end of
cycle On or Off
Alarm beep Control
AlarmBeep Internal beeper sounds for alarms On or Off
* includes ramping setpoints during profiles and controlled ramps
** power fail recovery time limit is always MM:SS regardless of time scale setting
*** high limit setpoint is a read-only item which is calculated on Enable page
