Sample Profile
Programming Table
Profile Number____1______
Profile Name__________
Seg-
ment
Ramp
Soak
Time
Events
Temp-
erature
Time
Events
1
2
3
4
1
2
3
4
1
01h00
100
01h00
2
02h00
50
00h01
3
00h00
4
5
6
7
8
High Limit Setpoint
115
Loop From Seg
No
Loop To Seg
No
Loop Number
0
Link To Pro
No
Guar Soak Band
10
