Dakota Ultrasonics

3.7 UTIL (utilities) – Menu

Mem Format: Allows the user to select between a general grid style format and
engine block format for data storage. Refer to page 60 for further info.
Scan Mode: This function enables a hi speed scan mode that increases the overall
sample rate from the standard 4 measurements a second to 32 measurements a
second. Refer to page 56 for further info.
Alarm Status: Toggles alarm mode on or off. Refer to page 57 for further info.

Alarm LO Limit: Gives the user the ability to set the LO limit parameter. If the
measurement falls below this value, a red light will illuminate and sound the internal
beeper. Refer to page 58 for further info.
Alarm HI Limit: Gives the user the ability to set the HI limit parameter. If the
measurement exceeds this value, a red light will illuminate and sound the internal
beeper. Refer to page 59 for further info.

3.8 XFER (transfer) – Menu

Backup Setups: Enables the user the ability to backup the setups currently stored
in the PR-8V to a PC via RS232 port. Refer the help section of the PR-8Vsonicview
software for a complete electronic manual.
Restore Setups: Enables the user the ability to restore the setups currently saved
on a PC to an PR-8V via RS232 port. Refer the help section of the PR-8Vsonicview
software for a complete electronic manual.
Backup Grid: Enables the user the ability to backup grids currently stored in the PR-
8V to a PC via RS232 port. Refer the help section of the PR-8Vsonicview software
for a complete electronic manual.
Restore Grid: Enables the user the ability to restore grids currently saved on a PC
to an PR-8V via RS232 port. Refer the help section of the PR-8Vsonicview software
for a complete electronic manual.
About: Provides the user with Dakota Ultrasonics contact information and the PR-
8V software version. Refer the help section of the PR-8Vsonicview software for a
complete electronic manual.
