A.4.3 COM Port LED
Message Description
LED off No data is transmitting on COM port
LED on blinking state Data is transmitting on COM port
Table 3. COM Port LED Message
A.4.4 RUN LED
Message Description
LED on Jumper JP1 pin1 and pin2 are short to disable AP firmware in
the flash memory.
LED blinking (rate: 0.5Sec) AP firmware is running
Table 4. RUN LED Message
