Chapter 2. System Overview
AirLive MW-2000S User’s Manual
5
Service Zones
y
Co-work with WLA-5000AP
With WLA-5000AP Multiple SSID function, MW-2000S can create and configure Multi-Service Zones.
y
Isolate Service Zones
With VLAN, Multiple SSID and Policy setting, MW-2000S can separate the Service Zones from being
accessed with each other.
y
Standalone Authentication system and customized template page
Each service zone can have its own settings:
•
NAT or router mode
•
Enable or disable DHCP service, and define DHCP address range
•
Enable or disable authentication
•
Type of authentication options (Local, LDAP, RADIUS, …)
•
Customized the Login, Logout, Redirected web page
•
Default Policy (Firewall rule, Specific route, Schedule, and Bandwidth)
•
Wireless Setting, SSID, and wireless security
Note: Please refer to the following chapter and learn more configurations to accomplish the Service Zones setting.
Chapter 5 – Multi-Service Providers
Chapter 6 – Multi-Service Zones
Chapter 7.1.7 – Service Zones
Appendix C – A Deployment Example of Service Zones
Local VPN
Data encryption means to encode the data so that confidential information can not be stolen by intruder. Since
wireless data can be received by anyone with a wireless device, the data encryption is even more important. The
current solution require administrator to set wireless encryption key on the wireless device. The problem with this
implementation is that when the key is known to one user, the entire network security is in jeopardy. The Local VPN
is the perfect solution to this problem. It is achieved in 5 easy steps.
z
Each user will be given a different account with username and password.
z
When user tries to access the network, a window will pop up to ask for the account information.
z
After user enters the correct password, the MW-2000S will download an ActiveX VPN client into the user’s
PC.
z
The VPN key is automatically assigned, the end user does not need to do anything.
z
After the account expired, the user will not be able to access the network anymore.
Note: Please refer to the following chapter and learn more configurations to accomplish the Local VPN setting.
Chapter 7.4.8 – VPN Configuration
Chapter 7.2.1.1 ~ 7.2.1.5 – Authentication Method (Local, POP3, RADIUS, LDAP, NT Domain)
Appendix G – Local VPN
Note: On-demand and SIP Authentication Method are not supported Local VPN function.
