Page 86
3-8
1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
Note: To determine Power or Gravity Down refer to page A.
0256527
CABLE/HOSE CLAMPS INSTALLATION (NOT SHOWN)
Ref.
8/G
1320224
Clamp, Loop 5/8"
10
3941406
Screw, Self-Tapping 1/4" x 3/4"
5
4240018
Tie-Strap 15”/38cm (Prior to S/N 38168)
10
4751400
Flatwasher 1/4" (Prior to S/N 38168)
5
4240033
Tie-Strap 7.5"/19cm
15
4460328
Connector, Strain Relief (Located On Platform)
1
(Prior to S/N 45030)
4460071
Connector, Strain Relief (Located On Platform)
1
(S/N 45030 to Present)
4240127
Tie-Strap 21"/53cm
4
4060807
Shield, Edge Trim
1 ft./30.5
1320095
Clamp
1
0641408
Bolt 1/4’-20NC x 1"
2
3311405
Nut 1/4"-20NC
2
FIGURE 3-2. SCISSOR ARMS INSTALLATION - 1532E (GRAVITY DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
