3120726 1532E/1932E 2033E/2046E 2646E/2658E 8-7
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-2. DECALS INSTALLATION - 1532E/1932E POWER DOWN MACHINES (COUNTRY SPEC)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to
page A.
0256975 DECAL INSTALLATION (COMMON PARTS) Ref. –
DECAL INSTALLATION (STANDARD PARTS) Ref. I
1 to 5 Not Used
6 Not Available Nameplate - Serial Number 1
7 1701504 Decal - Hydraulic Oil 1
8 1701508 Decal - Fork Lift Area 6
9 Not Used
10 0860520 Box, Manual Storage 1
11 1060279 Cable, Lanyard 1
12 1701509 Decal - Manual 1
13 Not Used
14 0641405 Bolt 1/4"-20NC x 5/8" 4
15 4751400 Flatwasher 1/4" 4
16 4761400 Lockwasher 1/4" 4
17 3311401 Nut 1/4"-20NC 4
18 Not Used
19 1702300 Decal - Tie Down 3
20 to 22 Not Used
23 3340564 Pad 2ft/61cm
24 2820024 Tubing, Vinyl 2ft/61cm
25 Not Used
26 1702939 Decal - Prop Location 1
27 3251813 Decal - Made in USA 1
28 1702773 Decal - JLG 3
29 Not Used
30 1702631 Decal - Bar Code 1
DECAL INSTALLATIONS (VARIABLE PARTS) Ref.
0256445 1532E CSA Spec (Canadian French) Ref. 6
0256479 1532E Japanese Spec Ref. 5
0256480 1532E Latin America Spanish Spec Ref. 5
0256603 1932E CSA Spec (Canadian French) Ref. 7
0256471 1932E Japanese Spec Ref. 6
0256470 1932E LATIN AMERICA SPANISH Ref. 6
51 Decal - Caution Options: 1
1701629 Canadian French
3252151 Japanese Spec
1701861 Latin America Spanish Spec
52 Decal - Danger Options: 1
3252115 Canadian French
3252149 Japanese Spec
1702556 Latin America Spanish Spec
