8-20 1532E/1932E 2033E/2046E 2646E/2658E 3120726
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-5. DECAL INSTALLATION - GRAVITY DOWN MACHINES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to
page A.
0257342 DECAL INSTALLATION (STANDARD PARTS) Ref. 5
1 to 20 Not Used
21 0860520 Box, Manual Storage 1
22 1060279 Cable, Lanyard 1
23 0641405 Bolt 1/4"-20NC x 5/8" 4
24 4751400 Flatwasher 1/4" 4
25 4761400 Lockwasher 1/4" (Prior to S/N 38529) 4
26 3311401 Nut 1/4"-20NC" (Prior to S/N 38529) 4
26 3311405 Locknut 1/4"-20NC" (S/N 38529 to Present) 4
27 3340564 Pad (Prior to S/N 46777) 2ft/61cm
28 Decal - Fork Lift Area Options: A/R
1703073 Prior to S/N 50425
1704016 S/N 50425 to Present
29 1701504 Decal - Hydraulic Oil 1
30 1701509 Decal - Manual 1
31 1702300 Decal - Tie-Down 3
32 1702939 Decal - Prop Location 1
33 Not Available Decal - Bar Code 1
34 1702773 Decal - JLG 3
35 1701510 Decal - Manual Descent 1
DECAL INSTALLATION (VARIABLE PARTS) Ref.
0257343 ANSI Spec without Power Deck Extension Ref. 4
0257364 ANSI Spec with Power Deck Extension Ref. 4
0257559 Brazil Spec 1532E/1932E Ref. 4
0257555 Brazil Spec 2033E/2046E/2646E/2658E Ref. 4
0257346 CSA Spec Canadian French Ref. 4
0257344 Japanese Spec without Power Deck Extension Ref. 4
0257592 Japanese Spec with Power Deck Extension Ref. 2
0257345 Latin American Spanish Spec Ref. 2
101 Decal Options: 1
1702954 ANSI Spec without Power Deck Extension
1702459 ANSI Spec with Power Deck Extension
1703552 Brazil Spec
1703392 Canadian French Spec
1702954 Japanese Spec without Power Deck Extension
1702459 Japanese Spec with Power Deck Extension
1703393 Latin American Spanish Spec
102 Decal - Crushing/Electrocution Options: 2
1703496 ANSI Spec
1703583 Brazil Spec
1703499 Canadian French Spec
1703497 Japanese Spec
1703498 Latin American Spanish Spec
