Page 62

2-8
1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
Note: To determine Power or Gravity Down refer to page A.
HYDRAULIC COMPONENTS INSTALLATIONS
Ref.
(VARIABLE PARTS)
0256420
Standard 2033E
Ref.
E
0256862
U/L 2033E
Ref.
B
0256422
Standard 2046E/2546E/2658E
Ref.
E
0256888
U/L 2046E/2546E/2658E
Ref.
B
51
Tray Options:
1
4845311
2033E Prior to S/N 24267
4845366
2033E S/N 24267 to Present
3539239
2046E/2546E/2658E Prior to S/N 24267
3539875
2046E/2546E/2658E S/N 24267 to Present
0255938
SIDE COVERS INSTALLATION - 2033E
Ref.
4/D
0255939
SIDE COVERS INSTALLATION - 2046E/2646E
Ref.
A
0255940
SIDE COVERS INSTALLATION - 2658E
Ref.
A
101
Cover Options:
1
3539445
2033E (Prior to S/N 33224)
4060937
2033E (S/N 33224 to Present)
3539446
2046E/2646E
3539447
2658E
102
0641408
Bolt, 1/4"-20NC x 1"
2
103
4751400
Flatwasher - 1/4"
4
104
3311405
Locknut - 1/4"-20NC
2
FIGURE 2-3. HYDRAULIC COMPONENTS AND COVERS INSTALLATION - 2033E/2046E/2646E/
2658E (POWER DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
