3120726 1532E/1932E 2033E/2046E 2646E/2658E 1-21
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIGURE 1-6. JLG POTHOLE PROTECTION SYSTEM INSTALLATION (POWER DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to Page A.
POTHOLE PROTECTION SYSTEM INSTALLATION Ref.
(STANDARD PARTS)
1 Not Used
2 4844987 Pivot Weldment 1
3 3538809 Plate, Cam 2
4 3538808 Plate, Cam 2
5 Not Used
6 3860065 Roller 1
7 4160133 Spring, Torsion 1
8 0362484 Bar, Link 4
9 0362485 Bar, Actuator 4
10 4160141 Spring, Extension 1
11 Not Used
12 0630398 Eye-Bolt 1
13 0362483 Bar, Roller 4
14 0961997 Bearing, Flange 4
15 Not Used
16 0961994 Bearing, Spacer 12
17 0641612 Bolt - 3/8"-16NC x 1 1/2" 4
18 4761600 Lockwasher - 3/8" 4
19 3440828 Roll Pin - 1/4" x 1 3/4" 2
20 4711800 Flatwasher - 1/2" Narrow 1
21 3440418 Roll Pin - 1/8" x 1 1/8" 1
22 3951005 Setscrew - #10-24NC x 5/8" 2
23 0961995 Bearing, Flange 4
24 0642224 Bolt - 3/4" - 10NC x 3" 4
25 3312205 Locknut - 3/4"-10NC 4
26 0961996 Bearing, Flange 8
27 0641611 Bolt - 3/8"-16NC x 1 3/8" 8
28 0100011 Loctite - #242 A/R
29 Not Used
30 0641508 Bolt - 5/16"-18NC x 1" 2
31 3311505 Locknut - 5/16"-18NC 2
32 4712400 Flatwasher 7/8" Narrow 1
33 Not Used
34 3911028 Screw Machine - #10-24NC x 1 3/4" 4
35 4751000 Flatwasher - #10 4
36 3311005 Locknut - #10-24NC 4
37 0641622 Bolt 3/8"-16NC x 2 3/4" 4
38 3311605 Locknut - 3/8"-16NC 4
39 Not Used
40 1120481 Cap, End (S/N 24267 to Present Only) 4
41 4460662 Connector, Strain Relief 2
42 Not Used
43 3311501 Nut 5/16”-18NC 2
