3120726 1532E/1932E 2033E/2046E 2646E/2658E 5-19
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-6. LIFT CYLINDER COMPONENTS ASSEMBLY (2033E/2046E POWER DOWN MACHINES
BUILT S/N 27085 TO PRESENT & 2646E/2658E POWER DOWN MACHINES BUILT S/N 26916 TO
PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to
page A.
LIFT CYLINDER SUB-ASSEMBLY Ref.
1 to 22 Not Used
23 0641506 Bolt 5/16"-18NC x 3/4" 4
24 0100011 Loctite #242 A/R
25 4640717 Cartridge, Valve (Manual Descent) 1
26 3311402 Nut, Jam 1/4"-20NC 1
27 0080190 Adapter 1
28 4220044 Stop, Throttle (Prior to S/N 28175 Only) 1
29 0902151 Bracket 1
30 Cable Assembly Options (Verify Length Before
Ordering): 1
1060377 112” Length
1060643 136” Length
30A 7019602 Bellows Kit (Use with 1060643 Cable Only) 1
30B 7019600 T-Handle (Use with 1060643 Cable Only) 1
31 3450405 Pin, Cotter 1
32 3321402 Nut, Jam 1/4"-28NF 4
33 4711400 Flatwasher 1/4" 4
34 3760170 Ring (Prior to S/N 28133 Only - Not Shown) 1
35 3841127 Rod, Manual Descent (Prior to S/N 28133 Only - Not 1
Shown)
LIFT CYLINDER ASSEMBLY Ref.
1683473 2033E/2046E Ref. –
1683474 2646E/2658E Ref. –
101 Kit O-Ring 1
102 Kit Ring, Back-up 1
103 Kit O-Ring 1
104 Kit Wiper 1
105 Kit O-Ring 1
106 Kit Seal 1
107 Kit Seal 2
108 Kit Ring, Guidelock 2
109 Kit Ring, Wear Options: A/R
2033E/2046E 1
2646E/2658E 2
110 Not Used
111 Locknut Options: 1
7003212 2033E/2046E
7003226 2646E/2658E
112 7005312 Plug (Not Shown) 1
113 7005315 Plug (Not Shown) 2
