JLG 2658E ANSI Parts Manual User Manual
Page 38
1-30
1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
0255784
HI-DRIVE LIMIT SWITCH INSTALLATION (OPTIONAL)
Ref.
3/C
301
4360397
Switch, Limit
1
3911024
Screw, Machine #10-24NC x 1 1/2"
2
4751000
Flatwasher #10
2
3311001
Nut #10-24NC
2
0100011
Loctite (Not Shown)
A/R
4761000
Lockwasher #10
2
0255950
HORN INSTALLATION (OPTIONAL)
Ref.
C
401
0140022
Horn
1
402
4921821
Harness (See Section 7 for Breakdown)
1
403
4360387
Switch, Push Button (Not Shown - Located on Platform
1
Console)
404
Not Used
405
0641408
Bolt 1/4"-20NC x 1"
1
406
4751400
Flatwasher 1/4"
2
407
3311405
Locknut 1/4"-20NC
1
BEACON LIGHT INSTALLATION (OPTIONAL)
Ref.
0255949
Non-UL Machines (Optional)
Ref.
4/F
0256859
U/L Machines
Ref.
1/A
501
Beacon Light Assembly Options:
1
2920119
Prior to S/N 23604
2920146
S/N 23604 to Present
501A
7016319
Bulb, Light
1
501B
Amber Lens Options:
1
7016320
Lens - 3 1/8" Height
7016372
Lens - 4 1/8" Height
502
4921822
Harness (See Section 10-7 for Breakdown)
1
503
4060865
Cage (Not Shown - U/L Machines Only)
1
504
0721006
Screw, Machine #10-24NC x 3/4"
2
505
4761000
Lockwasher #10
2
506
Not Used
507
4751000
Flatwasher #10
4
508
3311001
Nut #10-24
2
110V GENERATOR INSTALLATION
Ref.
0256790
1532E/1932E
Ref.
A
0256785
2033E
Ref.
A
0255962
2046E/2646E/2658E
Ref.
E
601
2460022
Generator
1
7023336
Repair Kit
1
602
Mounting Bracket Options:
1
0902344
1532E/1932E
0902341
2033E
0902340
2046E/2646E/2658E
603
4751500
Flatwasher 5/16"
8
604
4751700
Flatwasher 7/16"
4
605
3311505
Locknut 5/16"-18NC
4
606
1060627
Cable
2
607 to 608
Not Used
609
0840027
Boot, Cable
2
610
0641510
Bolt 5/16"-18NC x 1 1/4"
2
611
3311505
Locknut 5/16"-18NC
2
FIGURE 1-8. FRAME MOUNTED COMPONENTS INSTALLATION (POWER DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
