JLG 2658E ANSI Parts Manual User Manual
Page 44
1-36
1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
0255784
HI-DRIVE LIMIT SWITCH INSTALLATION (OPTIONAL)
Ref.
5/D
301
4360397
Switch, Limit
1
3911024
Screw, Machine #10-24NC x 1 1/2"
2
4751000
Flatwasher #10
2
3311001
Nut #10-24NC
2
0100011
Loctite (Not Shown)
A/R
4761000
Lockwasher #10
2
4460662
Connector, Strain Relief (S/N 46829 to Present)
1
1060680
Cable, Electrical - 18/2 (S/N 46829 to Present)
78in/2m
0255950
HORN INSTALLATION (OPTIONAL)
Ref.
4
401
0140022
Horn
1
402
4921988
Harness (See Section 7 for Breakdown)
1
403
4360387
Switch, Push Button (Not Shown - Located on Platform
1
Console)
404
Not Used
405
0641408
Bolt 1/4"-20NC x 1"
1
406
4751400
Flatwasher 1/4"
2
407
3311405
Locknut 1/4"-20NC
1
0255949
BEACON LIGHT INSTALLATION (OPTIONAL)
Ref.
0255949
Non-UL Machines (Optional)
Ref.
6/D
0256859
U/L Machines
Ref.
2/A
501
2920146
Beacon Light Assembly Options:
1
501A
7016319
Bulb, Light
1
501B
Amber Lens Options:
1
7016320
Lens - 3 1/8" Height
7016372
Lens - 4 1/8" Height
502
4921822
Harness (See Section 10-7 for Breakdown) (Prior to
1
S/N 44696)
1060341
Harness (See Section 10-7 for Breakdown) (S/N 44696
10ft/3.0m
to Present)
503
4060865
Cage (Not Shown - U/L Machines Only)
1
504
0721006
Screw, Machine #10-24NC x 3/4"
2
505
4761000
Lockwasher #10
2
506
Not Used
507
4751000
Flatwasher #10
4
508
3311001
Nut #10-24
2
509 to 512
Not Used
513
4460044
Holder, Fuse (S/N 44696 to Present)
1
514
2400056
Fuse, AGC-1/2 0.5A, 250V (S/N 44696 to Present)
1
GENERATOR INSTALLATION
Ref.
0256790
110V - 1532E/1932E
Ref.
4
0257174
220V - 1532E/1932E
Ref.
1
0256785
110V - 2033E
Ref.
4
0257173
220V - 2033E
Ref.
1
0255962
110V - 2046E/2646E/2658E
Ref.
8
0257172
220V - 2046E/2646E/2658E
Ref.
1
601
Generator Options:
1
2460022
110 Volt
7023336
Repair Kit
1
2460031
220 Volt
FIGURE 1-9. FRAME MOUNTED COMPONENTS INSTALLATION (GRAVITY DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
