SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-8. SCISSOR ARMS INSTALLATION - 2646E/2658E (GRAVITY DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0257120 COMMON MACHINES Ref. 5
0257121 CANADIAN MACHINES Ref. 5
0257641 JAPANESE MACHINES Ref. 4
Note: To determine Power or Gravity Down refer to page A.
1 Not Used
2 0200531 Arm Weldment (Bottom Inboard) (Standard) 1
0200564 Arm Weldment (Bottom Inboard) (Japanese Spec) 1
3 0200532 Arm Weldment (Lower Mid Inboard) 1
4 0200533 Arm Weldment (Bottom and Top Outboard) 2
5 0200537 Arm Weldment (Lower and Upper Mid Outboard) 4
6 3422483 Pin 2
7 3422484 Pin 2
8 3422485 Pin 2
9 0641524 Bolt 5/16"-18NC x 3" 8
10 3422483 Pin (Common) 5
3422587 Pin (Canada Only) 5
11 3422488 Pin 2
12 1683502 Lift Cylinder Assembly (See Section 5 for Breakdown) 1
13 3340629 Pad, Slide Block 4
14 3422597 Pin (Common) 2
3422589 Pin (Canada Only) 2
15 4740438 Washer, Special 20
16 3760387 Ring, Retaining 20
17 0641522 Bolt 5/16"-18NC x 2 3/4" 2
18 4711500 Flatwasher 5/16" Narrow 8
19 4751500 Flatwasher 5/16" Regular 8
20 3311505 Locknut 5/16"-18NC 24
21 4240125 Bushing, Split 1
22 0681520 Bolt 5/16"-18NC x 2 1/2" Grade 8 12
23 to 33 Not Used
34 0962010 Bushing, Garmax 8
35 0962010 Bushing, Garmax 12
36 0200536 Arm Weldment (Top Inboard) 1
37 4845475 Prop, Safety 1
38 0641508 Bolt 5/16"-18NC x 1" 2
39 0200535 Arm Weldment (Upper Mid Inboard) 1
40 Pad Options: 3
3340645 Prior to S/N 47288 (Polyurethane)
3340841 S/N 47288 to Present (PVC)
41 4240128 Strap 1
42 1670837 Cover, Arm (Japanese Spec) 1
43 4711400 Flatwasher (Japanese Spec) 4
44 3941406 Self Tapping 1/4" (Japanese Spec) 4
– – – – – – – – – –
2901504 Arm Kit - 2646E/2658E (Includes Items 2-5, 36, 37 & 39) 1 1
2901525 Arm Kit - 2033E/2046E (Includes Items 2-5, 36, 37 & 39) 1 A
(Japanese Spec)
0252587 ARM PADS INSTALLATION Ref. 3
101 Pad Options: 24
3340645 Prior to S/N 47288 (Polyurethane)
3340841 S/N 47288 to Present (PVC)
