SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
Note: To determine Power or Gravity Down refer to page A.
0256527 CABLE/HOSE CLAMPS INSTALLATION (NOT SHOWN) Ref. 5/E
1320224 Clamp, Loop 5/8" 10
3941406 Screw, Self-Tapping 1/4" x 3/4" 5
4240018 Tie-Strap 15”/38cm 10
4751400 Flatwasher 1/4" 5
4240033 Tie-Strap 7.5"/19cm 15
4460328 Connector, Strain Relief (Located On Platform) 1
4240127 Tie-Strap 21"/53cm 4
FIGURE 3-1. SCISSOR ARMS INSTALLATION - 1532E (POWER DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
