Page 241

3120726
1532E/1932E 2033E/2046E 2646E/2658E
9-1
S
E
C
T
I
O
N
9
R
E
C
O
M
M
E
N
D
E
D
S
E
R
V
I
C
E
P
A
R
T
S
S
T
O
C
K
SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODELS 1532E/1932E/2033E/2046E/2646E/2658E
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-4
5-9
10 OR MORE
STANDARD PARTS
7018525
Breaker, Circuit - AC (Figure 1-10)
1
1
1
7011509
Breaker, Circuit - DC (Figure 1-10)
1
1
1
7013711
Coupling (Figures 2-1, 2-2, 2-3 and 2-4)
1
1
1
2120072
Element, Filter (Figures 2-1, 2-2, 2-3 and 2-4)
4
8
12
1340052
Breather (Figures 2-1, 2-2, 2-3 and 2-4)
1
2
3
7018311
Coil, Valve Cartridge (Figure 2-5)
1
1
1
7018917
Coil, Valve Cartridge (Figure 2-5)
1
1
1
7016352
Coil, Valve Cartridge (Figure 2-5)
1
1
1
1600286
Controller, JLG SMART System TM (Figure 2-6)
1
1
1
4360070
Breaker, Circuit (Figure 2-6)
1
1
1
4360432
Switch, Key (Figure 2-6)
1
1
1
2860030
Key, Replacement (Figure 2-6)
1
1
1
4360328
Switch, Toggle (Figure 2-6)
1
1
1
4360289
Switch, Emergency Stop (Figures 2-6 and 4-10)
1
1
1
3740069
Relay (Figure 2-6)
1
1
1
1600276
Controller, Directional (Figure 4-10)
1
1
1
0610123
PC Board (Figure 4-10)
1
1
1
7017444
Coil, Valve Cartridge (Figures 5-4 and 5-7)
1
1
1
VARIABLE PARTS
4360401
Limit Switch (Figures 1-6, 1-7 & 4-7)
1
1
1
4360397
Limit Switch (Figures 1-8 & 1-9)
1
1
1
4360434
Switch, Tilt Indicator (Optional) (Figure 1-9)
1
1
1
4360321
Limit Switch (1000 Lbs Machines) (Figure 1-9)
1
1
1
7011552
Switch, 50-60HZ (Japanese Spec) (Figure 1-10)
1
1
1
3740130
Relay (Common) (Figure 2-6)
1
1
1
3740121
Relay (U/L Listed) (Figure 2-6)
1
1
1
4360403
Switch Membrane With Tilt Light (Figure 4-10)
1
1
1
4360450
Switch Membrane Without Tilt Light (Figure 4-10)
1
1
1
