3120726 1532E/1932E 2033E/2046E 2646E/2658E 2-15
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-5. VALVE ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to page A.
VALVE ASSEMBLY (STANDARD PARTS) Ref.
1 Not Serviced Block, Valve 1
2 7018300 Cartridge, Valve (Shuttle) 1
7018301 Seal Kit - 7018300 Cartridge 1
3 7018302 Cartridge, Valve (Main Relief) 1
7016351 Seal Kit - 7018302 Cartridge 1
4 7018919 Cartridge, Valve (Steer Relief) 2
7016351 Seal Kit 2
5 Not Used
6 7018304 Cartridge, Valve (High Drive Check) 1
7016351 Seal Kit - 7018304 Cartridge 1
7 Not Used
8 7018305 Cartridge, Valve (Counterbalance) 2
7016337 Seal Kit - 7016338 Cartridge 2
9 7018307 Cartridge, Valve (Brake) 1
7018308 Seal Kit - 7018307 Cartridge 1
10 7018303 Cartridge, Valve (Lift Relief Up) 1
7016351 Seal Kit - 7018303 Cartridge 1
11 7018312 Cartridge, Valve (Tow) 1
7018313 Seal Kit - 7018312 Cartridge 1
12 7012793 Rexroth Valve Section (Steer) 1
7012773 Seal Kit 1
12A 7018912 Nut 2
12B 7018917 Coil 2
13 7012794 Rexroth Valve Section - Lift Up/Lift Down (Power Down) 2
Rexroth Valve Section - Lift Up/High Drive (Gravity Down) 2
7012773 Seal Kit 1
13A 7018912 Nut 2
13B 7018917 Coil 2
14 7012794 Rexroth Valve Section (Drive) 2
7012773 Seal Kit 1
14A 7018912 Nut 2
14B 7018917 Coil 2
15 7018314 Cartridge, Valve (Flow Divider) 1
7018315 Seal Kit - 7018314 Cartridge 1
16 7018309 Cartridge Without Coil (Posi-Trac) 1
7018310 Seal Kit - 7018309 Cartridge 1
16A 7018311 Coil 1
17 3931032 Capscrew, Socket Head #10-24NC x2" 12
18 Not Used
VALVE ASSEMBLY (VARIABLE PARTS) Ref.
4640951 Power Down Machines Ref. B
4641004 Gravity Down Machines (Prior to S/N 41086) Ref. A
4641021 Gravity Down Machines (S/N 41086 to Present) Ref. A
51 Cartridge, Without Coil (High Drive) Options: A/R
7016348 Power Down Machines 1
7016349 Seal Kit - 7016348 Cartridge 1
Not Required Gravity Down Machines 0
51A Coil Options: A/R
7016352 Power Down Machines 1
Not Required Gravity Down Machines 0
